EN ANALOG MEDICAL GAS SHUT OFF VALVES SYSTEM
Analog Medical Gas Shut Off Valves System is a safety device installed within medical gas pipeline systems to isolate the gas supply during emergency situations or critical incidents. Designed for use in hospitals and healthcare facilities, this valve provides a rapid and reliable method to stop the flow of medical gases such as oxygen, nitrous oxide, medical air, vacuum, and other medical gas services when required.
Specification
- Analog Medical Gas Shut Off Valves System is mainly used in medical pipeline to allow maintenance of individual zone without disturbing the gas flow to other zones. In case of emergencies, zone valve box can also be used to shutoff of gas distribution to individual zone. A single box can hold from 1 to 7 valves, allowing control of 7 types of gas.
- Designed to house up to seven shut-off valves, each valve controls a different gas
- Wall mount style
- Accept valve sizes 1/2 through 2 inches
- Temperature -20-60℃;Humidifier 10%-95%
- Maximum pressure of Oxygen, Air(4bar), N2O, CO2 is 0.8MPa without leakage
- Maximum pressure of N2 and Air(7bar) is 1.2MPa without leakage
- Maximum pressure of VAC is -0.075MPa without leakage
